Sale! Woofer/Midrange Speaker Driver – 6.5 Inch
$47.61
$52.90
Quick Overview
These Response woofers are excellent for replacement or for new speaker design constructions. Not only are they price competitive and perform very well, but they also look fantastic!The concave treated paper cone matched with rubber surround provides smoot
- Satisfaction 100% Guaranteed
- Free shipping on orders over $30
- 60 day easy Return
These Response woofers are excellent for replacement or for new speaker design constructions. Not only are they price competitive and perform very well, but they also look fantastic!
The concave treated paper cone matched with rubber surround provides smooth overall response. Equipped strong steel frame baskets, high power magnet and voice coils, these drivers will produce massive quantities of clean bass output for any musical application.
Specifications:
| Driver Material | Coated Paper |
| Nominal Impedance | 8 |
| RMS Power Rating | 60W |
| Frequency Response | 44Hz-7kHz |
| Sensitivity (SPL@1W, 1m) | 89dB |
| Resonant Frequency | 49.5Hz |
| Driver Channels | Single Driver |
| Side-to-Side Diameter (A) | 178mm |
| Recommended Speaker Box Volume | 19l |
| Mechanical Q (Qms) | 2.02 |
| Electrical Q Factor (Qes) | 0.57 |
| Magnetically Shielded | No |
| Total Q (Qts) | 0.44 |
| Equivalent Volume (Vas) | 19l |
| DC Coil Resistance (Re) | 6 |
| Speaker Type | Woofer/Midrange |
| Mounting Hole Diameter (B) | 168mm |
| Cutout Diameter (C) | 145mm |
| Insert Depth (D) | 77mm |
| Cutout shape | Round |
| Mounting Method | Front of Panel |
| Attachment / Securing Method | Screw Down |
| Diameter | 178mm |
Downloads
- Download Datasheet
| Cost: | $25 |
| Free Shipping | We offer free shipping on orders over $30. Please check the free - shipping eligibility at checkout. |
| Delivery Time: | It usually takes [3-5] business days for standard shipping. Please note that this is an estimated time frame and may be affected by local holidays, and unforeseen circumstances. |
Reviews
There are no reviews yet.
