Sale! Powertech Miniature 12V 3A PWM Solar Charge Controller
$32.31
$35.90
Quick Overview
This compact solar controller uses Pulse Width Modulation (PWM) to manage battery charging from a connected solar panel. It features light and timer control, similar to street lights, and three charging states (bulk, equalise, and float charging). It provi
- Satisfaction 100% Guaranteed
- Free shipping on orders over $30
- 60 day easy Return
This compact solar controller uses Pulse Width Modulation (PWM) to manage battery charging from a connected solar panel. It features light and timer control, similar to street lights, and three charging states (bulk, equalise, and float charging). It provides all the important safety features such as overcharge, over-discharge, over-current, short-circuit, and reverse-polarity protection.
Features:– Red charge LED indicator- Green power LED indicator- Hang hook- Battery voltage automatic identification- PWM charging mode- Comprehensive electronic protection
Specifications:Rated Voltage: 12VStrong Charging Pressure: 14.8VEquilibrium Charging: 14.5VFloat Charging Pressure: 13.7VUnder Voltage: 10.8VUnder Recover Voltage: 13VNonLoad Current: 6mACharging Circuit Voltage drop: 0.2VDischarge Circuit Voltage drop: 0.1V
Specifications:
| Max Charging Current | 3A |
| Charge Controller Technology | Pulse Width Modulated (PWM) |
| Max Load Current | 3A |
| DC Voltage | 12V |
| Dust/Particle Ingress Protection | 2 – Objects > 12.5mm, Fingers or small objects |
| Liquid/Moisture Ingress Protection | 2 – Dripping water when tilted to 15deg |
| IP Rating | 22 |
| Width | 52mm |
| Height | 22mm |
| Depth | 80mm |
| Weight | 33g |
Downloads
- Download Manual
| Cost: | $25 |
| Free Shipping | We offer free shipping on orders over $30. Please check the free - shipping eligibility at checkout. |
| Delivery Time: | It usually takes [3-5] business days for standard shipping. Please note that this is an estimated time frame and may be affected by local holidays, and unforeseen circumstances. |
