Traditional laminated iron core transformers suitable for new projects, hobby projects or as a replacement in existing equipment. They have a thermal fuse built into the primary winding for added safety and a wide variety is available to suit your specific needs.
Twin outputs may be wired in series to increase voltage or in parallel (in phase only) to increase current.
Primary Connection: 200mm Fly Leads
Conforms to AS/NZ 61558.2.6
Specifications:
| Type of Transformer |
Laminated Core |
| Case Type |
2170 |
| Primary Winding Connection |
Flyleads |
| Secondary Winding Connection |
Solder Tags |
| Secondary Winding Configuration |
Multi-tapped |
| Temperature Rise Above Ambient at Rated Power |
70C |
| Regulation |
7% |
| Core Material |
Laminated Iron |
| Magnetising Current |
80mA |
| Thermal Fuse |
Yes |
| Mount Spacing (A) |
91mm |
| Core Winding Depth (D) |
76mm |
| Case Length (L) |
80mm |
| Case Width (W) |
44mm |
| Case Height (H) |
68mm |
| Type of converter or transformer |
laminated/toroidal transformer |
| Mains Voltage Range |
240V |
| Max Input Power |
100VA |
| Rated for AU Mains |
Yes |
| AC Voltage rating |
12V,12V,15V,15V |
| Cost: |
$25 |
