Sale! Parallel Jow Connector Clamp 20A – Pack of 2
$10.71
$11.90
Quick Overview
Designed to reduce electrical installation time and to increase efficiency. These easy-to-use connectors eliminates the need to strip, twist and crimp connect wires. Simply insert your wire into the clamp opening and snap it shut using your hands or small
- Satisfaction 100% Guaranteed
- Free shipping on orders over $30
- 60 day easy Return
Designed to reduce electrical installation time and to increase efficiency. These easy-to-use connectors eliminates the need to strip, twist and crimp connect wires. Simply insert your wire into the clamp opening and snap it shut using your hands or small pliers depending on wire gauge to make the connection. The precision-sharpened connector blades borrows the IDC configuration that cut through the wires create a connection.
Available in two shapes – “I” type and “T” type. “I” type are used for end to end connections whereas the “T” type for parallel connections. Ideal for applications such as: low voltage LEDs, residential, automotive, communication and broadcasting.
Features:
Avoid stripping, twisting or crimping cables together
Eliminates need to tape cables
Creates an IP33 connection
Electrically Safety approved
Handles up to 600VAC
RoHS compliant
Max current (240VAC): 20A
Connection loss (Ohm): 0.0001
Specifications:
| Length | 37mm |
| Width | 7.7mm |
| Height | 7.7mm |
| Weight | 3.3g |
| Type of quick connector | Splice |
| Wire Gauge | 13AWG-12AWG |
| Pack Quantity | 2pc |
| Wire Size (Cross Section) | 2.5mm |
| Cost: | $25 |
| Free Shipping | We offer free shipping on orders over $30. Please check the free - shipping eligibility at checkout. |
| Delivery Time: | It usually takes [3-5] business days for standard shipping. Please note that this is an estimated time frame and may be affected by local holidays, and unforeseen circumstances. |
