Sale! 12V 8100 RPM DC Electric Motor
$10.71
$11.90
Quick Overview
Torque 180 g-cm Voltage: 12VAT STALL Torque (G.CM): 372 Current (AMP): 5.21AT MAX POWER Output (W): 13.57 Speed (RPM): 8266 Torque (G.CM): 160 Current (AMP): 2.4DIMENSIONS Diameter: 27.66mm Total Length: 57mm Shaft Length: 13mm Shaft dia: 2.3mm Mounting th
- Satisfaction 100% Guaranteed
- Free shipping on orders over $30
- 60 day easy Return
Torque 180 g-cm
Voltage: 12V
AT STALL
Torque (G.CM): 372
Current (AMP): 5.21
AT MAX POWER
Output (W): 13.57
Speed (RPM): 8266
Torque (G.CM): 160
Current (AMP): 2.4
DIMENSIONS
Diameter: 27.66mm
Total Length: 57mm
Shaft Length: 13mm
Shaft dia: 2.3mm
Mounting thread dia: 2.6mm
Specifications:
| Motor Type | High Speed |
| Motor Nominal Voltage | 12V |
| No load current | 0.28A |
| No load RPM | 14500RPM |
| Full load current | 4.3A |
| Full load torque | 520g.cm |
| Max efficiency | 66.1% |
| Max efficiency power | 5.56W |
| Max efficiency RPM | 10950RPM |
| Maximum efficiency torque | 100g.cm |
| Max. efficiency current | 1.5A |
| Shaft diameter | 2.3mm |
| Shaft length | 13mm |
| DC Voltage | 12V |
| Length | 57mm |
| Diameter | 26.66mm |
| Diameter | 2.3mm |
| Length | 13mm |
| Cost: | $25 |
| Free Shipping | We offer free shipping on orders over $30. Please check the free - shipping eligibility at checkout. |
| Delivery Time: | It usually takes [3-5] business days for standard shipping. Please note that this is an estimated time frame and may be affected by local holidays, and unforeseen circumstances. |
