Sale! 10 Pin 0.156 Straight Locking Header with Crimp Pins – 3.96 pitch
$12.60
$14.00
Quick Overview
The contacts are rated at 250V @ 7A AC/DC which makes them an ideal power connector to a PCB. They are end to end stackable and commonly seen as the output connector on Switchmode power supplies.Features:- Wire Pull- Out force: 2.85kg- Unmating Force: 150g
- Satisfaction 100% Guaranteed
- Free shipping on orders over $30
- 60 day easy Return
The contacts are rated at 250V @ 7A AC/DC which makes them an ideal power connector to a PCB. They are end to end stackable and commonly seen as the output connector on Switchmode power supplies.
Features:
– Wire Pull- Out force: 2.85kg
– Unmating Force: 150g
– Durability: 25 cycles
– Housing: Nylon, UL 94V- 2
– Temperature: – 40 to 105C
Specifications:
| Operating Temperature | 150C |
| Type | Single Row Header |
| Device | Plug |
| Attachment Method | Crimp |
| Number of Pins | 10pc |
| Pin Spacing | 4mm (5/32″) |
| Pack Quantity | 1pc |
| Pin Size | 0.1mm |
| Insulation Dielectric Voltage Rating | 1500V |
| Insulation Resistance | 500M |
| header locking | Yes |
| header polarised | Yes |
| Mating Force | 199gg |
| Contact Insertion Force | 681g |
| Contact Retention to Housing | 3.63kg |
| DC Voltage | 250V |
| DC current rating | 2.5A |
| AC current rating | 2.5A |
| Mounting Method | PCB |
