Sale! 10 Pin 0.1 Straight Locking Header – 2.54 pitch – Single
$11.70
$13.00
Quick Overview
A range of connectors for PCB mounting that allow circuit boards to be plugged together at right angles or end-to-end, or cables to be plugged onto circuit boards at right angles or end-on at the edge of the PCB. Both plugs and sockets may be butted up end
- Satisfaction 100% Guaranteed
- Free shipping on orders over $30
- 60 day easy Return
A range of connectors for PCB mounting that allow circuit boards to be plugged together at right angles or end-to-end, or cables to be plugged onto circuit boards at right angles or end-on at the edge of the PCB. Both plugs and sockets may be butted up end-to-end to form connectors with any number of ways from 2 upwards.
Both plugs are wafer design into which square, tin-plated brass pins have been inserted. These pins protrude 3.4mm on one side, and should be soldered to the PCB. The nylon wafer sits on the PCB and is 3.3mm thick. The back provides locking and polarising.
Features:
Normal force: 200g min
Housing: UL 94v-0 white nylon
Temperature: 0 to +75C
Specifications:
| Operating Temperature | 75C |
| Type | Single Row Header |
| Device | Socket |
| Attachment Method | Crimp |
| Number of Pins | 10pc |
| Pin Spacing | 2.54mm (0.1″) |
| Pack Quantity | 1pc |
| Pin Size | 0.9mm |
| Insulation Dielectric Voltage Rating | 1500V |
| Insulation Resistance | 50M |
| header locking | Yes |
| Right Angle Mount | Yes |
| header polarised | Yes |
| Mating Force | 199gg |
| Contact Insertion Force | 681g |
| Contact Retention to Housing | 3.63kg |
| DC Voltage | 250V |
| DC current rating | 2.5A |
| Mounting Method | PCB |
| Length | 7.6mm |
| Width | 14.2mm |
| Height | 6.3mm |
| Cost: | $25 |
| Free Shipping | We offer free shipping on orders over $30. Please check the free - shipping eligibility at checkout. |
| Delivery Time: | It usually takes [3-5] business days for standard shipping. Please note that this is an estimated time frame and may be affected by local holidays, and unforeseen circumstances. |
